Call now to book your rental!
860-573-3125
CATERPILLAR
COMPACT TRAK LOADER
289D3
RENTAL RATES
DAILY $ 400
WEEKLY $ 1400
MONTHLY $ 4200
Overview
Compact Trak Loader
Compact Trak Loader
The Cat® 289D3 Compact Track Loader, with its vertical lift design, delivers extended reach and lift height for quick and easy truck loading. Its standard, suspended undercarriage system provides superior traction, flotation, stability and speed to work in a wide range of applications and underfoot conditions.
Product Specifications
OPERATING SPECIFICATIONS
Rated Operating Capacities - 35% Tipping Load 2890 lb
Tipping Load 8255 lb
Breakout Force - Tilt Cylinder 7291 lb
Rated Operating Capacity with Optional Counterweight 4370 lb Rated Operational Capacities- 50% Tipping Load 41.30 lb Ground Pressure - With 450 mm/17.7 in. Track 4.7 psi
Ground Contact Area- With 450 mm/17.7 in. Track 2272 in2
DIMENSIONS
Length- Track on Ground 64.2 in
Overall Length- Track 83.8 in
Height- Top of Cab 83.2 in
Ground Clearance 8.9 in
Departure Angle 33°
Maximum Dump Angle 51°
Clearance at Maximum Lift and Dump 94 in
Turning Radius from Center- Machine Rear 70.7 in
Length- Without Bucket 117.9 in
Maximum Reach- With Arms Parallel to Ground 50 in
Turning Radius from Center-Bucket 88.8 in
Reach- Maximum Lift/Dump 30 in
Length- With Bucket on Ground 146.2 in
Maximum Overall Height 158.1 in
Rack Back Angle- Maximum Height 84°
Vehicle Width (450 mm/17.7 in tracks) 78 in
CAT289D3 ATTACHMENTS
AUGER daily: $200 weekly: $700
AUGER DRILL BIT 18" daily: $75 weekly: $280
AUGER DRILL BIT 12" daily: $60 weekly: $240
POWER ROCK RAKE/ HARLEY RAKE daily: $300 weekly: $900 monthly: $2700
*Note - Operating Weight, Operating Specifications, and Dimensions all based on 75 kg (165 lb) operator, all fluids, two speed, OROPS, 2036 mm (17.7 in) tracks, dual flange front idler/single flange rear idler, standard flow hydraulics, mechanical suspension seat, no optional counterweights and manual quick coupler (unless otherwise noted).
